As a premier manufacturer and global supplier of heavy-duty industrial processing equipment, we introduce the CNC High Speed Plate Drilling Machine Model PHD4040-2.
Engineered for absolute precision and rigorous operational demands, this equipment transforms raw steel plates into ready-to-assemble structural components with unmatched accuracy.
Features a massive 4000x4000mm working area designed specifically for oversized plates and heavy structural elements.
Equipped with dual vertical ram-type drilling spindles for highly efficient, synchronous machining operations.
Powered by the advanced FAGOR 8055 CNC system, ensuring flawless execution of complex engineering blueprints.
Built upon a robust gantry structure guided by premium heavy-load linear roller pairs for uncompromising stability.
Step onto the production floor and the first thing you notice is the commanding presence of the CNC High Speed Plate Drilling Machine Model PHD4040-2. The rigid, heavy-duty bed and gantry structure exude industrial strength, meticulously designed to absorb the intense vibrations of high-speed metal penetration. When the dual 22 kW variable-frequency motors roar to life, the sound is a steady, reassuring hum of sheer power, driving the Taiwan precision spindles through thick steel with effortless grace. Every movement of the cross beam slides is fluid and precise, guided by premium heavy-load linear roller pairs and driven by precision ball screws. This is not merely a machine; it is the beating heart of a modern fabrication facility.
The tactile finish of the machined components reveals a mirror-like smoothness, a testament to the flawless synergy between the advanced FAGOR CNC system and the high-pressure inner cooling mechanisms. By automating the most labor-intensive aspects of plate drilling, this equipment drastically reduces cycle times, minimizes human error, and elevates the overall output quality of your production line. It is an investment in relentless productivity, transforming complex engineering blueprints into tangible reality with absolute consistency. Whether you are processing massive bridge girders or intricate heat exchanger tube sheets, this drilling center delivers an unparalleled combination of brute force and microscopic precision.
Achieving superior fabrication results requires equipment that anticipates the challenges of heavy industry. This drilling center is meticulously engineered to eliminate bottlenecks in your production workflow, ensuring every hole is positioned and executed with absolute perfection.
Uncompromising Structural Integrity: The foundation of this equipment lies in its heavily ribbed machine bed and gantry, providing the rigid stability necessary to maintain microscopic tolerances during aggressive drilling cycles.
Synchronized Dual-Slide Architecture: Two movable slides on the cross beam operate independently or synchronously, effectively doubling your throughput without expanding the machine's footprint.
Intelligent Hole Preview: The integrated automatic programming software allows operators to visualize hole positions prior to machining, virtually eliminating costly material waste caused by programming errors.
Effortless Tool Management: Featuring a disk spring automatic broach mechanism and hydraulic cylinder cutter release, tool changes are executed swiftly, keeping downtime to an absolute minimum.
Meeting the strict tolerances of complex engineering blueprints requires machining capabilities that push the boundaries of conventional equipment. This system is built to tackle the most demanding structural components with ease, directly addressing the pain points of heavy steel fabrication.
Expansive Processing Envelope: The massive 4000 x 4000 mm worktable accommodates oversized plates, allowing for the continuous processing of large-scale components without the need for constant repositioning.
Deep Penetration Power: Capable of piercing through solid workpieces up to 250 mm in thickness, providing the brute force required for heavy structural engineering and thick tube sheets.
Versatile Drilling Diameters: Designed to utilize both high-speed steel twist drills up to φ50mm and carbide drills up to φ40mm, offering the flexibility to adapt to various material hardness levels and hole specifications.
Consistent Output Quality: The heavy-duty ram-type feeding mechanism ensures the drill bit maintains a perfectly perpendicular trajectory, preventing hole deviation even at maximum penetration depths.
The longevity and reliability of industrial machinery are directly tied to the pedigree of its internal components. We have partnered with industry-leading brands to construct a drilling center that withstands the test of time and continuous operation, establishing a foundation of trust and high precision.
FAGOR 8055 Control Center: At the brain of the operation is the Spanish FAGOR 8055 CNC system, offering robust 6-axis control for complex, multi-dimensional machining tasks with highly intuitive operator interfaces.
Taiwan Precision Spindles: Equipped with BT50 taper spindles renowned for their exceptional rotational stability and minimal runout, ensuring pristine hole finishes and extended tool life.
Heavy-Load Linear Roller Guides: The integration of premium roller guide pairs ensures frictionless, ultra-precise longitudinal movements, drastically reducing mechanical wear over years of service.
High-Torque AC Servo Drives: Paired with large-pitch precision ball screws, these servo motors deliver rapid, stutter-free positioning of the gantry and spindle slides.
In an era where production speed dictates market leadership, this equipment is engineered to maximize operational uptime and minimize manual intervention. Lowering labor costs while boosting capacity is the ultimate goal of this intelligent system.
Simultaneous Dual-Spindle Operation: The ability to drive two independent spindles synchronously slashes cycle times in half for symmetrical or repetitive hole patterns across large plates.
Seamless CAD/CAM Integration: The advanced software suite translates digital designs directly into executable machining programs, bypassing tedious manual data entry and accelerating setup times.
Continuous Chip Evacuation: A robust chain-plate type automatic chip-conveyor, paired with a dedicated collection trolley, removes metal shavings instantly, preventing work area clutter and thermal buildup.
Automated Lubrication Network: A centralized auto-lubricating system delivers precise amounts of oil to critical moving parts at scheduled intervals, eliminating the need for manual greasing and preventing premature component failure.
Tooling consumables represent a significant ongoing expense in metal fabrication. This machine incorporates advanced thermal management systems to protect your investments, ensure continuous high-speed cutting, and make tool transitions incredibly convenient.
Dual-Action Cooling Mechanism: Utilizing both a high-pressure inner cooling pump and a low-pressure outer cooling pump, the system floods the cutting zone with coolant, rapidly dissipating heat from both the core and the exterior of the drill bit.
Advanced Coolant Filtration: An integrated paper filter system continuously purifies the cooling fluid, removing microscopic metal particles that could otherwise cause abrasive wear on the spindle and tooling.
Hydraulic Tool Release: The dedicated 6.5MPa hydraulic system facilitates smooth, shock-free cutter loosening, protecting the delicate spindle taper from mechanical stress during rapid tool changes.
Thermal Deformation Prevention: By maintaining optimal cutting temperatures, the cooling system prevents the workpiece from warping, ensuring dimensional accuracy across massive spans of metal.
Procuring capital equipment requires absolute confidence in the manufacturer's quality assurance protocols. Our production facilities operate under the most stringent international standards to guarantee flawless equipment delivery and long-term operational safety.
ISO 9001:2015 Quality Management: Every stage of manufacturing, from raw material inspection to final assembly, is governed by rigorous quality control checkpoints to ensure zero defects.
ISO 14001:2015 Environmental Management: Our production processes are optimized to minimize environmental impact, reflecting a deep commitment to sustainable industrial practices.
ISO 45001:2018 Occupational Health & Safety: The equipment is designed and built in a facility that prioritizes the highest safety standards, ensuring the final product is intrinsically safe for your operators.
Global Compliance Standards: Fully certified with CE and CCC marks, guaranteeing seamless integration into facilities worldwide while meeting strict regional safety and electrical directives.
The commissioning of your machine is just the beginning of our partnership. We provide a comprehensive support ecosystem designed to eliminate cross-border procurement anxieties and ensure your production line never misses a beat.
Comprehensive 12-Month Warranty: Enjoy complete peace of mind with a full year of coverage following successful installation and commissioning, including the free replacement of any defective spare parts.
Round-the-Clock Global Support: Our dedicated technical team is available 24/7 via WeChat, WhatsApp, or high-definition video calls to provide immediate troubleshooting and diagnostic assistance.
Localized Engineering Presence: Benefit from our network of international service engineers, ready to be dispatched to your local market for on-site maintenance and rapid issue resolution.
Expert Operator Training: Following installation, our master technicians conduct in-depth, hands-on training sessions covering mechanical, electrical, and hydraulic operations to empower your workforce.
Lifetime Technical Backing: We guarantee permanent technical support and priority access to paid spare parts for the entire operational lifespan of your equipment.
Selecting the right equipment partner is a strategic decision that impacts your bottom line for decades. We stand apart by delivering not just machinery, but comprehensive manufacturing solutions tailored to elevate your operational capabilities.
Unrivaled Manufacturing Pedigree: Decades of specialized experience in designing heavy-duty CNC machinery translates into equipment that consistently outperforms and outlasts the competition.
Direct-from-Manufacturer Value: By eliminating intermediaries, we provide premium, high-performance machinery at highly competitive price points, maximizing your return on investment.
Rigorous Pre-Shipment Testing: Every machine undergoes exhaustive simulated production runs before leaving our facility, ensuring it arrives at your floor ready for immediate, heavy-duty operation.
Customized Engineering Solutions: We understand that no two production lines are identical. Our engineering team collaborates closely with you to adapt our technology to your specific workflow requirements.
