| PPHD123 is a combined steel plate processing machine with multiple functions,which can drill,punch&mark with the Max.punching force up 1200KN and drilling rotation speed up to 300RPM.It is mainly used to process connecting plates in tower industry with very high efficiency.The working process is numerical controlled and the operation is convenient.It can realize automatic,high-precision and mass production. | |||||||||
As a premier manufacturer and supplier, we introduce the CNC High-Speed Punching, Marking & Drilling Machine PPHD123 for Plates. Engineered for heavy-duty metal fabrication, this equipment streamlines complex structural plate processing with unparalleled precision and reliability.
Integrates punching, marking, and drilling into one seamless, automated workflow.
Handles plate thicknesses up to 40mm with a devastating 1200KN punching force.
Features advanced CNC architecture for rapid, error-free, and high-volume production.
Step onto the production floor, and the first thing you will notice is the quiet, rhythmic hum of the CNC High-Speed Punching, Marking & Drilling Machine PPHD123 for Plates. Crafted with robust, heavy-gauge steel framing, this machine exudes industrial durability, designed specifically to withstand the relentless demands of high-volume metal fabrication. The tactile feel of the premium control panel, combined with the smooth glide of the universal supporting balls under heavy steel plates, speaks volumes about the meticulous engineering poured into every component. By consolidating three critical operations—punching, marking, and drilling—into a single, fluid process, it eliminates the need to transfer heavy workpieces between multiple stations, drastically cutting down handling time and floor space requirements.
Beyond its imposing physical presence, this equipment is a sophisticated problem-solver for modern structural engineering facilities. The integration of world-class hydraulic valves and high-torque servo motors ensures that every punch lands with devastating power yet microscopic precision. When the carbide drill bites into a 40mm thick steel plate, the vibration is minimal, a testament to the rigidly balanced BT50 spindle. The resulting holes are clean, burr-free, and perfectly aligned, ensuring that downstream assembly processes proceed without costly rework or delays. The clear, deeply embossed markings left by the 1200KN character box provide permanent traceability, essential for stringent quality control in critical infrastructure projects. Investing in this machinery means transforming raw steel into precision-engineered components with a level of consistency that elevates your entire production capability.
Engineered to maximize operational throughput while minimizing manual intervention, this plate processing center is packed with features that directly translate to bottom-line improvements. Every mechanical and electronic system is optimized for speed, accuracy, and extreme longevity.
Tri-Functional Processing Station: Seamlessly transition between drilling, punching, and marking without repositioning the workpiece, drastically reducing cycle times and eliminating manual alignment errors.
Frictionless Material Handling: The worktable is embedded with heavy-duty universal supporting balls, allowing massive steel plates to glide effortlessly. This reduces operator fatigue and prevents surface scratching on premium materials.
Rapid-Lock Hydraulic Clamping: Two incredibly strong, precision-engineered hydraulic clamps secure the material instantly. Their freely adjustable distance accommodates a vast array of plate dimensions with zero slippage during high-torque drilling.
Intuitive Human-Computer Interface: The upper computer software requires minimal training. Operators simply input the desired processing dimensions, and the system automatically generates the optimal tool path, eliminating complex manual programming.
Premium Component Architecture: Built exclusively with internationally recognized brands for the PLC, ball screws, servo motors, and hydraulic valves, ensuring continuous, breakdown-free operation even in the harshest manufacturing environments.
When dealing with massive structural components, raw power and processing speed are non-negotiable. This equipment is engineered to chew through heavy workloads with relentless efficiency, ensuring your production targets are consistently met without compromising on quality.
Massive Force Generation: Delivers a staggering 1200KN of punching and marking force, effortlessly piercing through dense materials and leaving crisp, permanent identification marks for lifetime traceability.
High-Velocity Spindle Dynamics: The drilling spindle operates at a maximum rotation speed of 3000r/min, utilizing premium carbide drills to slice through metal rapidly while simultaneously extending tool life.
Substantial Workpiece Capacity: Capable of accommodating large-scale plates up to 1500x800mm and thicknesses ranging from 5mm to 40mm, making it the ultimate solution for heavy infrastructure and architectural projects.
Multi-Die Versatility: Equipped with three distinct die-stations, allowing for the simultaneous setup of three different punching diameters, or two punches alongside a dedicated marking character box, minimizing downtime during tooling changeovers.
In structural engineering, a millimeter of deviation can lead to catastrophic assembly failures or severe project delays. This machine guarantees absolute dimensional accuracy, ensuring every component fits perfectly on the construction site right out of the box.
Micro-Level Accuracy: Maintains a longitudinal and transverse hole spacing precision of ±0.5mm, virtually eliminating the need for manual reaming, forced fitting, or adjustments during final structural assembly.
Strict Standard Adherence: Fully compliant with the rigorous stipulations of first-rate products in the Classifying Standard of Steel Tower of the Transmit Electricity Line, guaranteeing immediate regulatory and inspector acceptance.
Flawless Node Plate Production: Achieves a highly controlled tolerance of ±1.0mm for space between hole groups and edge distances, ensuring maximum structural integrity in critical load-bearing joints.
Exceptional Verticality: The punching mechanism maintains a vertical degree error of less than 0.03 times the plate thickness (and ≤ 2mm), ensuring massive structural bolts slide through cleanly for secure, rapid fastening.
Downtime is the enemy of profitability. By integrating only the highest echelon of internal mechanical and electronic components, this machine promises unwavering stability and a significantly extended lifecycle under continuous, multi-shift operation.
World-Renowned Electronics: The PLC and servo control systems are sourced from globally trusted brands, providing lightning-fast signal processing that remains completely immune to industrial electrical noise and interference.
Precision Linear Motion: High-grade ball screws govern the X, Y, and Z axes, translating motor rotation into smooth, exact linear movements with zero backlash, ensuring the cutting tool is exactly where it needs to be.
Robust Fluid Power: The dual-pressure hydraulic system (High pressure 24MPa / Low pressure 6MPa) utilizes premium valves to deliver consistent, shock-free force application during every single punch and clamp cycle.
Thermal and Vibration Management: The heavy cast and welded frame absorbs operational vibrations, while the highly efficient 22KW oil pump motor maintains optimal fluid temperatures during marathon production runs.
Transforming complex manufacturing into a streamlined, user-friendly process is at the heart of this machine's design philosophy. It empowers operators of all skill levels to achieve expert-level fabrication results with minimal physical exertion.
Automated Program Generation: The intelligent software instantly translates raw dimensional inputs into executable CNC code, bypassing the steep learning curve associated with traditional G-code programming.
Dynamic Axis Control: Three independent CNC axes (X, Y, Z) maneuver the heavy plates at rapid traverse speeds up to 15m/min, orchestrating a ballet of heavy metal with pinpoint accuracy and zero hesitation.
Ergonomic Material Handling: The strategic placement of universal supporting balls creates a near-frictionless surface, allowing operators to position multi-ton plates with surprisingly little effort, enhancing workplace safety.
Instantaneous Clamping: The dual hydraulic clamps engage and disengage in fractions of a second, drastically reducing loading and unloading times between cycles and keeping the spindle working continuously.
Acquiring heavy machinery is the beginning of a long-term partnership. We stand firmly behind our equipment with a comprehensive, global support ecosystem designed to keep your operations running smoothly year after year.
Round-the-Clock Assistance: Access our dedicated technical support team 24/7 via WeChat, WhatsApp, or high-definition video calls for immediate troubleshooting and operational guidance.
Global On-Site Expertise: We maintain a network of international service engineers ready to be dispatched directly to your facility for hands-on maintenance, complex issue resolution, and system optimization.
Comprehensive Warranty Coverage: Enjoy a standard 12-month warranty post-installation, during which all necessary replacement parts are provided entirely free of charge, protecting your initial investment.
Permanent Technical Backing: Long after the warranty expires, you retain full access to our engineering experts for software updates, operational advice, and immediate paid spare parts availability.
End-to-End Training: Following a successful commissioning, our engineers provide exhaustive on-site training covering mechanical, electrical, and hydraulic systems to ensure your team is fully proficient and confident.
