| PP103B CNC plate punching&marking machine is mainly used to process connecting plates in tower industry.It is a combined machine with multiple functions.The working process is numerical controlled and the operation is convenient.It can realize automatic,high-precision and mass production. | |||||||||
As a premier manufacturer and dedicated supplier of industrial metal fabrication equipment, we present the CNC Punching & Marking Machine PP103B. Engineered for heavy-duty structural steel processing, this system seamlessly integrates multi-die punching and clear character marking into one fluid, highly efficient operation.
Engineered for processing steel plates from 5 to 25 mm in thickness.
Delivers a massive 1000 kN of punching force for effortless material penetration.
Features three rapid-change die stations to accommodate varying hole diameters.
Streamlined automated operation designed for high-volume, continuous production.
Step onto the production floor and experience the rhythmic, powerful operation of a machine built for uncompromising structural fabrication. The CNC Punching & Marking Machine PP103B transforms raw steel plates into precision-engineered components with remarkable fluidity. When the robust hydraulic clamps secure the metal, you can physically feel the stability of the heavy-duty framework locking into place. As the 1000 kN punching cylinder engages, it delivers a deep, resonant strike, cleanly piercing through solid steel up to 25 mm thick without hesitation, leaving behind a perfectly cylindrical void free of burrs or material distortion. The universal supporting balls beneath the workpiece ensure that even massive, cumbersome steel plates glide effortlessly across the table, drastically reducing mechanical friction and operator physical strain.
Beyond raw power, this equipment is a testament to meticulous craftsmanship and intelligent design. The integrated marking station leaves deep, crisp, and highly legible alphanumeric characters embedded permanently into the metal surface, ensuring lifelong traceability for critical infrastructure components. By integrating world-class servo motors and precision ball screws, the machine executes every complex movement with a quiet, deliberate hum, reflecting its exceptional internal engineering. This synergy of immense hydraulic force and micro-level CNC accuracy eliminates the need for manual measuring or secondary processing. It drastically accelerates your production timeline while ensuring every single connection plate, flange, or structural node aligns perfectly during the final assembly of towers, bridges, or industrial frameworks.
Elevate your fabrication workflow with intelligent engineering designed to solve real-world production bottlenecks. This machine is specifically crafted to minimize operational downtime and maximize output consistency across demanding shifts.
Triple Die-Station Versatility: Seamlessly transition between three distinct hole diameters. The quick-change tooling system eliminates tedious manual punch replacements, keeping your production lines moving without unnecessary interruptions.
Frictionless Material Handling: The work table features integrated universal supporting balls that create a smooth, low-resistance surface. Heavy steel plates glide into position effortlessly, protecting the material finish and reducing the wear on positioning motors.
Adaptive Hydraulic Clamping: Two formidable, highly precise hydraulic clamps secure the workpiece with unyielding force. Their distance can be instantly and freely adjusted to accommodate varying plate dimensions, preventing any material shifting during high-impact punching.
Intuitive HMI Software: The human-computer interface strips away complex coding requirements. Operators simply input the dimensional requirements and hole coordinates, and the sophisticated upper computer software autonomously generates the optimal processing program.
Designed to meet the rigorous demands of modern infrastructure development, this equipment blends heavy-duty mechanical performance with intelligent automation, ensuring your facility remains competitive and compliant with stringent industry tolerances.
Unmatched Processing Efficiency: Combining hole punching and character marking in a single setup, the equipment effortlessly handles 25 mm thick plates. The multi-station die setup ensures rapid transitions, significantly boosting batch processing speeds for large-scale projects.
Exceptional Precision & Stability: Driven by premium AC servo motors and guided by high-end ball screws, the X and Y axes achieve a longitudinal and transverse hole-spacing accuracy of ±0.5 mm. This strict adherence to tolerances perfectly aligns with the exacting standards required for electricity transmission towers and structural engineering.
World-Class Core Components: Built for endurance in harsh industrial environments, the internal architecture features internationally renowned brands for the hydraulic pump, pneumatic valves, PLC control system, and servo motors, guaranteeing a exceptionally low failure rate and an extended operational lifespan.
Broad Application Adaptability: This machine serves as the backbone of production for power transmission fittings, communication tower brackets, building steel structures, automotive chassis components, and large-scale energy equipment such as wind turbine foundation rings.
Certified Manufacturing Excellence: Produced under strict adherence to global standards, our manufacturing processes are fully certified, including ISO9001 for quality management, ISO14001 for environmental responsibility, and ISO45001 for occupational health and safety.
