| This machine can punch,mark and cut angles with the size up to ∠200*200*20.It is the ideal equippment to process big angles.It has single blade cutting with the cutting capacity up to 4300KN,there is no any waste of angle for each cutting. | |||||||||
Engineered as a premier automated solution by a leading manufacturer for heavy-duty structural steel fabrication.
Seamlessly integrates high-speed punching, precise marking, and clean shearing into a single, highly efficient platform.
Designed to process massive raw materials up to ∠200×200×20 mm with an impressive feeding speed of 40 meters per minute.
Provides unmatched reliability for industrial suppliers looking to scale up production while minimizing manual labor and material handling.
The CNC Punching Marking and Cutting Machine APM2020B for Angles represents the absolute pinnacle of structural steel processing technology. When standing beside this massive, meticulously engineered production line, the sheer rigidity of its heavy-duty steel frame communicates unwavering stability. The rhythmic, powerful thud of the 1100 KN hydraulic punching cylinders and the clean, decisive snap of the single-blade shearing unit demonstrate a machine built to conquer the toughest raw materials. Every mechanical component is coated in industrial-grade, corrosion-resistant paint that feels smooth yet incredibly durable to the touch, ensuring the equipment withstands the harsh, abrasive realities of a busy fabrication floor.
By consolidating punching, marking, and cutting into a single, continuous automated workflow, this machine drastically reduces material handling time and eliminates the hazardous bottleneck of transferring heavy steel angles between separate manual stations. The air-cooled hydraulic system hums with quiet efficiency, driving the high-rigidity clamp arms and feeding mechanisms with fluid, unyielding precision. Operators will immediately appreciate the absence of jagged edges and metal waste, thanks to the innovative single-blade cutting technology that leaves a mirror-smooth, perfectly neat finish on every single cut. This is not just a piece of machinery; it is a comprehensive, intelligent solution designed to elevate your production capacity, minimize labor dependency, and deliver flawless structural components that consistently meet the strictest engineering tolerances.
Engineered to redefine heavy-duty fabrication, this angle processing line boasts an array of advanced features designed to maximize output while minimizing operational friction. Every mechanism is crafted to deliver tangible improvements to your daily manufacturing workflow.
Triple-Die Punching Versatility: Each side of the punching unit is equipped with three sets of dies moved by numerical control, allowing instant switching between different hole diameters without manual intervention.
Waste-Free Shearing Technology: The advanced single-blade cutting unit slices through heavy steel with immense force, leaving a pristine, neat surface without generating any material waste.
Seamless Material Handling: The transverse conveyor automatically supports and transmits raw materials, transitioning smoothly into the longitudinal feeding conveyor via a robust reducer-driven rotating mechanism.
Leak-Resistant Hydraulics: Utilizing premium sleeve-type connections in the hydraulic pipelines ensures a clean, oil-free working environment and drastically simplifies routine maintenance.
Pneumatic Finished Product Discharge: Finished angles up to 12 meters in length are swiftly and safely rotated to the side by a powerful pneumatic conveyor system, keeping the production line moving without interruption.
Time is the most critical asset in large-scale structural manufacturing. This equipment is specifically optimized to accelerate your production timelines without compromising on structural integrity. By integrating multiple processes, it transforms raw steel into ready-to-assemble components in record time.
High-Speed Throughput: Achieves an impressive feeding speed of 40 meters per minute, allowing you to process massive volumes of raw material in a fraction of the time compared to traditional methods.
Exceptional Hole Production: Capable of punching approximately 1000 holes per hour, ensuring your assembly lines never wait for components and project deadlines are consistently met.
Heavy-Duty Capacity: Effortlessly handles massive angle sizes ranging from ∠63×63×4 mm up to a staggering ∠200×200×20 mm, accommodating the most demanding structural engineering requirements.
All-in-One Consolidation: By merging punching, marking, and cutting into one continuous flow, it eliminates the need for multiple machines, dramatically reducing floor space requirements and associated labor costs.
Accuracy is non-negotiable when fabricating components for towering structures. The intelligent control architecture of this machine guarantees that every hole and cut aligns perfectly with your engineering blueprints, eliminating costly rework on the construction site.
Servo-Driven Accuracy: The CNC feeding carriage is powered by a highly responsive servo motor and guided by heavy-duty linear rails, ensuring pinpoint positioning accuracy for every single workpiece.
Universal Software Compatibility: The advanced upper computer system effortlessly reads and converts processing files from mainstream lofting software, including DSTV, DXF, NC, and CAM formats, bridging the gap between design and manufacturing.
Automated Program Generation: Operators simply input the processing requirements or upload the design files, and the intelligent system automatically generates the precise machining program, completely eliminating human calculation errors.
Intuitive Visual Interface: Features a user-friendly man-machine interface that displays real-time workpiece graphics, vast data storage, location data, and instant fault alarms for immediate troubleshooting and seamless operation.
Industrial machinery must endure relentless physical stress day in and day out. The APM2020B is constructed with an uncompromising focus on mechanical rigidity and innovative engineering solutions to withstand the brutal forces of heavy metal processing.
Closed-Rigidity Marking Unit: The marking station features a highly rigid, closed-frame design that ensures deep, perfectly legible character impressions even under an immense 1030 KN of nominal marking force.
Customizable Character Cassettes: Equipped with four sets of character cassettes selected via intelligent programming, allowing for flexible, clear, and permanent component identification essential for complex assembly tasks.
Zero-Waste Cutting Craftsmanship: The single-blade shearing mechanism is a masterpiece of engineering, providing a clean, distortion-free cut with a nominal force of 4300 KN that saves material costs and eliminates the need for secondary grinding.
Optimized Hydraulic Architecture: The entire hydraulic support system is designed with premium sleeve-type fittings, completely eradicating the common industry headache of fluid leakage, maintaining a clean workspace, and simplifying maintenance routines.
The true value of a production line lies in its continuous uptime and reliability. We have selected only the highest-grade internal components to guarantee fault-free operation in the most punishing and dust-filled industrial environments.
Robust Hydraulic Powerhouse: The central hydraulic system effortlessly manages high-load, repetitive tasks such as pressing materials, supporting heavy angles, punching, and cutting with consistent, unwavering force and precision.
Advanced Servo Motors: Premium servo drives provide the rapid acceleration, deceleration, and immense torque required for high-speed material feeding while maintaining absolute positional control over heavy steel profiles.
Industrial-Grade Control Unit: The integrated CNC system is housed in a heavily protected enclosure, shielded from factory dust, vibrations, and electrical interference to prevent unexpected downtime and ensure continuous data processing.
Reliable Air Cooling Integration: An highly efficient air-cooling system continuously maintains optimal operating temperatures for the hydraulic fluid and internal electronics, ensuring the machine performs flawlessly during extended, multi-shift production schedules.
Versatility is key for modern fabrication facilities looking to diversify their capabilities. This angle processing line serves as the backbone equipment for a diverse array of critical infrastructure, commercial construction, and specialized engineering sectors.
Power Transmission Infrastructure: Absolutely essential for manufacturing the heavy-duty structural components, cross-arms, and bracings required for high-voltage power transmission towers and regional substations.
Telecommunications & Railway Engineering: Perfectly suited for fabricating high-precision angle parts used in the construction of 5G communication masts, railway signal towers, and robust track support frameworks.
Large-Scale Steel Structures: The go-to automated solution for processing angle steel utilized in expansive commercial building frameworks, heavy-duty factory structures, architectural curtain wall supports, and industrial storage shelving.
Mechanical Manufacturing Frameworks: Highly effective for producing standardized, high-strength angle steel components such as heavy machine bases, equipment frames, and secure installation brackets for various industrial applications.
Acquiring heavy machinery is a long-term commitment, and we stand firmly behind our equipment long after the final installation is complete. Our global support network ensures your production never stops and your operators remain confident.
Round-the-Clock Online Assistance: Our dedicated technical support team is available 24/7 via WeChat, WhatsApp, or video call to provide immediate troubleshooting, software guidance, and operational advice.
On-Site Global Engineering: We proactively deploy experienced international service engineers directly to your local market for hands-on installation, rigorous mechanical commissioning, and comprehensive operator training.
Permanent Technical Backing: Enjoy lifetime technical support from our specialized engineering department, ensuring your machine continuously evolves with your production needs and software updates.
Worry-Free Spare Parts Guarantee: Benefit from readily available, free spare parts during the standard 12-month warranty period, with guaranteed, fast-tracked availability of paid spares for the entire operational lifespan of the equipment.
Trust is built on verifiable, internationally recognized standards. Our manufacturing processes adhere to the strictest global protocols, ensuring every machine delivered is a testament to operational safety, environmental sustainability, and superior build quality.
ISO 9001:2015 Quality Certified: Our rigorous quality management system guarantees that every component, from the smallest structural bolt to the massive main hydraulic cylinder, meets exact engineering specifications and performance criteria.
ISO 14001:2015 Environmentally Compliant: We are deeply committed to sustainable manufacturing, utilizing environmentally responsible processes, minimizing waste, and reducing our ecological footprint during the production of heavy machinery.
ISO 45001:2018 Safety Standards: Occupational health and safety are paramount; our equipment is designed with comprehensive safety interlocks, emergency stops, and protective systems to safeguard your valuable workforce.
Global Procurement Confidence: These prestigious, internationally recognized certifications provide complete peace of mind, significantly reducing the risks associated with cross-border equipment acquisition and ensuring compliance with local regulations.
Partnering with a premier manufacturer means securing a definitive competitive advantage in your fabrication capabilities. We do not just supply machinery; we deliver comprehensive, end-to-end production solutions engineered for absolute reliability and maximum return on investment.
Decades of Engineering Excellence: Our deep-rooted expertise in structural steel processing equipment translates into machines that are intuitively designed, incredibly resilient, and built to outperform standard market offerings.
Direct Manufacturer Pricing Structure: By completely eliminating third-party intermediaries, we provide top-tier, industrial-grade equipment at highly competitive rates, maximizing your procurement budget and accelerating your ROI.
Advanced Customization Capabilities: We understand that no two fabrication facilities are identical. Our engineering team can tailor layout configurations, conveyor lengths, and specific processing parameters to match your exact floor plan.
Uncompromising Material Selection: We meticulously source only the highest-grade raw materials, reinforced steel alloys, and premium electronic components, ensuring that our machines deliver decades of profitable, uninterrupted service.
End-to-End Strategic Partnership: From the initial technical consultation and factory layout planning to final on-site commissioning and extensive operator training, we are with you at every step of the operational journey.
